VIBZ 8 DC 8 Channel Mixing

VIBZ 8 DC 8 Channel Mixing

8 Channel Mixing Console with DFX and Compressor

Specifications

-Channels  8

Mono Channels:

-Mono Mic and Line Input Channels  4

-Mono Mic input connectors 6.3 mm TRS, XLR

-Channel Inserts 2

-Channel Insert Connectors 6.3 mm TRS

-Mono Mic Input Type  Electronically balanced

-Mono Mic Input Frequency Range  10 - 45000 Hz

-Amplification Range mono Mic Input 0 - 50 dB

-Mono Mic Input Input THD-N  0.0058%

-Mono Mic Input Impedance  4k Ohm(s)

-Mono Mic Input S/N Ratio  113 dB

-Mono Line Input Type  Electronically balanced

-Mono Line Input Frequency Range  10 - 45000 Hz

-Amplification Range mono Line Input  0 - 50 dB

-Mono Line Input Input THD-N 0.0045 %

-Mono Line Input Impedance  21k Ohm(s)

-Mono Line Input S/N Ratio  113 dB

-Mono Channel Equalizer High  +/- 15 dB @ 12000 Hz

-Mono Channel Equalizer Mid +/- 15 dB @ 2500 Hz

-Mono Channel Equalizer Low +/- 15 dB @ 80 Hz

-Controls Mono Mic and Line Input Channels  3-band EQ (High, Mid, Low), AUX (DFX) Post, Channel    Volume, Compressor (channel 1+2), Gain, Low Cut (75 Hz), pan

-Phantom power  48 V DC switchable

Stereo Channels:

-Stereo Line Input Channels  3

-Stereo Line Input Connectors 6.3 mm TRS

-Stereo Line Input Type  Unbalanced

-Stereo Line Input Frequency Range  10 - 45000 Hz

-Amplification Range stereo Line Input  0 - 50 dB

-Stereo Line Input Input THD-N  0.0045 %

-Stereo Line Input Impedance  3,7k Ohm(s)

-Stereo Line Input S/N Ratio  116 dB

-Stereo channel equalizer treble  +/- 15 dB @ 12000 Hz

-Stereo channel equalizer mids  +/- 15 dB @ 2500 Hz

-Stereo channel equalizer bass  +/- 15 dB @ 80 Hz

-Controls Stereo Line Input Channels  2-band EQ (High,Low), 3-band EQ (High, Mid, Low), AUX     (DFX)   Post, Balance, Channel Volume, Gain, Low Cut

Main Section:

-AUX / Effects Send Channels  1

-AUX / Effects Send Connectors  6.3 mm stereo jack unbalanced

-Stereo AUX Return Channels  1 x stereo

-Stereo AUX Return Connectors  2 x 6.3 mm TRS

-Stereo Tape Out Channel  1 x stereo

-Stereo Tape Out Connectors  2 x RCA (Cinch)

-Stereo Tape In Channel  1 x stereo

-Stereo Tape In Connenctors  2 x RCA (Cinch)

-Max. Unbalanced Stereo Main Out Level  20 dBu

-Indicators  8-segment Level Meter, Channel Peak, DFX Peak / Mute, Phantom Power, Power

-Operating voltage  18V DC - 1 A, External PSU, 230 V

-Width  265 mm

-Height 78 mm

-Depth  352 mm

-Weight  2,3 kg
